Science Highlight: September 12, 2018

Human neural stem cells drive spine regeneration in rats

Stem cells maintained in culture renewed long regions of spinal cord in rat transplant model

NIBIB-funded researchers generated stable lines of spinal cord neural stem cells in a laboratory dish. Once transplanted into a rat model of spinal cord injury, the cells enabled robust regeneration of functional neurons along the length of the spine.

The research team from the University of California, San Diego, used human pluripotent stem cells (hPSCs) to create and maintain spinal cord neural stem cells (NSCs) that became multiple types of neurons when transplanted into a rat model of spinal cord injury. The NSCs regenerated extensive regions of the spinal cord and large numbers of functional axons that extended over long distances to innervate their target tissues. The studies were supported, in part, by the National Institute of Biomedical Imaging and Bioengineering (NIBIB) and reported in the September issue of Nature Methods1

Neural stem cells differentiate in rat spinal injury model

(h) Spinal cord neural stem cells (green) grafted into rat spinal injury at dotted line extend into injured area and differentiate into mature neurons (purple). (i) Close-up (box) shows axons of transplanted neural stem cells (green fibers) extending beyond area of transplantation into injury site. Credit: Kumamaru, et al. Nat Meth-Sept 2018

“Scientists have been very enthusiastic about the potential to use neural stem cells to treat a number of spinal cord disorders including spinal cord injury, amyotrophic lateral sclerosis, and spinal muscular atrophy,” said Rosemarie Hunziker, Ph.D., director of the NIBIB Tissue Regeneration Program. “A real bottleneck in bringing this innovation to patients, however, is the ability to control the cell’s identity as a particular functional nerve cell, while preserving its ability to proliferate and provide a large number of these cells.”

Types of spinal neurons

The research was led by senior author Mark H. Tuszynski, M.D., Ph.D., Professor of Neurosciences, Center for Neural Repair, University of California, San Diego. The challenge for Tuszynski and his colleagues was to develop a system to grow large numbers of NSCs in cell culture to be used as a reliable source for transplantation. The problem they had to overcome was the tendency of these cells to change into different types of neural cells, which causes them to stop growing. This severely limits the number of undifferentiated NSCs that can be produced for experiments.

The group used human embryonic stem cells (hESCs) treated with various combinations of proteins such as fibroblast growth factor that encourages growth. An important addition to the mix, which further prompted undifferentiated cell growth was proteins that block factors in the cell that inhibit growth. “Our concoction both drove cell growth and removed factors that block cell growth, resulting in a cell line of spinal cord neural stem cells that we were able to keep growing and expanding,” said Tuszynski.

A critical aspect of the novel cell culture system was that it kept the cells growing as neural stem cells, while maintaining their ability to become different types of neural cells when placed in an environment such as the site of spinal injury in the rat model.

green neural stem cells differentiate into purple neurons

Neural stem cells (green) differentiate into mature neurons (purple) following transplantation into rat spinal cord injury model. Right: close up of single cell showing expression of neural stem cell marker (green) and marker indicating differentiation into mature neuron (purple). Credit: Kumamaru, et al. Nat Meth-Sept 2018

“With the ability to expand and maintain large numbers of undifferentiated neural stem cells, we believe that advancement to human clinical trials could be in a time frame of as little as five years,” said first author Hiromi Kumamaru, M.D., Ph.D. “However, the safety and efficacy of the cells will first have to be established in additional studies in rats and non-human primates.”

Beyond transplantation therapies, Tuszynski explained that their ability to differentiate the NSCs into multiple types of spinal cord neurons should prove extremely valuable for disease modelling in cell culture to test potential therapies for a variety of neural disorders including amyotrophic lateral sclerosis and progressive muscular atrophies.

This work was supported by grants from the National Institute of Biomedical Imaging and Bioengineering and the National Institute of Neurological Disorders and Stroke, both components of the National Institutes of Health, the Veterans Administration, the Craig H. Neilsen Foundation, the Japan Society for the Promotion of Science, the Bernard and Anne Spitzer Charitable Trust, and the Dr. Miriam and Sheldon G. Adelson Medical Research Foundation.

1. Generation and post-injury integration of human spinal cord neural stem cells. Kumamaru H, Kadoya K, Adler AF, Takashima Y, Graham L, Coppola G, Tuszynski MH. Nat Methods. 2018 Sep;15(9):723-731
